News & Updates

Voltage-controlled attenuators characterised

Product Description RFMD’s RFSA3013 is a fully monolithic analog voltage controlled attenuator (VCA) featuring exceptional linearity over a minimum temperature compensated 30dB gain control range. It incorporates a revolutionary new circuit architecture to solve a long standing industry problem: high IP3, high attenuation range, low DC current, broad bandwidth and temperature compensated linear in dB […]

Voltage-controlled attenuators characterised Read More »

IBM scientists achieve storage memory breakthrough

The current memory landscape spans from venerable DRAM to hard disk drives to ubiquitous flash. But in the last several years PCM has attracted the industry’s attention as a potential universal memory technology based on its combination of read/write speed, endurance, non-volatility and density. For example, PCM doesn’t lose data when powered off, unlike DRAM,

IBM scientists achieve storage memory breakthrough Read More »

ST has MEMS gyro for more than

The L3G4IS is the first three-axis MEMS gyroscope that enables both user interface and image stabilization applications at the same time. Thanks to two different independent reading chains and digital interfaces, the L3G4IS delivers previously unseen levels of flexibility to the end user. Each reading chain and the corresponding full-scale can be activated by powering

ST has MEMS gyro for more than Read More »

4.5Amps Bipolar Stepper Motor driver based on TB6600

Features Based on Single chip and Second chip for auto half current control Suitable for Nema17, Nema23, Nema34 bipolar stepper motors Suitable for 4Wires, 6 wires and 8 wires stepper motor. Forward and reverse rotations available Selectable Phase (Micro-step) drives 1/1, 1/2, 1/4, 1/8, and 1/16 Maximum Input supply 42V DC Minimum Input supply 10V

4.5Amps Bipolar Stepper Motor driver based on TB6600 Read More »

$Frequency translator works on fractionals$

Frequency translator works on fractionals

IDT FemtoClock® NG Universal Frequency Translators (UFT™) cover all your frequency synthesis and translation needs. Family members are available that support 1, 2, 3 or 4 PLL’s in a single package. As a frequency synthesizer, a low-cost, readily-available fundamental mode crystal can be used to generate output frequencies that range from 1 MHz to 1.3 GHz.

Frequency translator works on fractionals Read More »

ODrive – High performance motor control

Description Stepper motors are ubiquitous in hobby robotics projects: If you make a robotics or automation project today, it is very likely you will use them. Almost all DIY projects from 3D printers and CNC mills, to other kinds of projects like air hockey robots, use them. However in industrial automation, brushless servomotors have taken

ODrive – High performance motor control Read More »

Range of I2C-bus NXP extends with no-offset buffer

The PCA9525 is a monolithic CMOS integrated circuit for bus buffering in applications including I²C-bus, SMBus, DDC, PMBus, and other systems based on similar principles. The buffer extends the bus load limit by buffering both the SCL and SDA lines, allowing the maximum permissible bus capacitance on both sides of the buffer. The PCA9525 includes

Range of I2C-bus NXP extends with no-offset buffer Read More »

TI claims zero-drift op amp first

Description The OPA2188 operational amplifier uses TI proprietary auto-zeroing techniques to provide low offset voltage (25 µV, max), and near zero-drift over time and temperature. This miniature, high-precision, low quiescent current amplifier offers high input impedance and rail-to-rail output swing within 15 mV of the rails. The input common-mode range includes the negative rail. Either

TI claims zero-drift op amp first Read More »

Easy IoT weather station with multiple sensors

A weather station is a fun project that teaches you a ton about electronics with the added benefit being an actually useful little device. The project requires a bunch of cheap parts and sensors totaling less than $15, and the whole thing ends up fitting in your hand. The station creates a web site that

Easy IoT weather station with multiple sensors Read More »

What is a zener diode?

A tutorial on zener diodes and how to use them as voltage clamps, voltage regulators, and how to create audio distortion circuits. For more detail: What is a zener diode?

What is a zener diode? Read More »
