Summary of LANTRONIX RELEASES OPEN-Q 5165RB SYSTEM-ON-MODULE FOR EDGE ROBOTICS APPLICATIONS
Lantronix released the Open-Q 5165RB system-on-module (SOM) and a companion development board based on the Qualcomm QRB5165 SoC, running Ubuntu Linux. The compact 29×50 mm SOM targets edge robotics and integrates AI, image, and graphics processing cores. The QRB5165 is built on a 7 nm process and features a Kryo 585 octa-core CPU (1×2.84 GHz, 3×2.42 GHz, 4×1.81 GHz), Hexagon 698 DSP, Adreno 650 GPU, and other dedicated processing units for advanced edge workloads.
Parts used in the Open-Q 5165RB:
- Open-Q 5165RB system-on-module (29×50 mm)
- Qualcomm QRB5165 System-on-Chip (7 nm)
- Kryo 585 Octa-core CPU (1×2.84 GHz, 3×2.42 GHz, 4×1.81 GHz)
- Hexagon 698 DSP
- Adreno 650 GPU
- Integrated development board with full headers
- Ubuntu Linux operating system (on-board support)
Lantronix has recently launched a system-on-module and its integrated development board based on Qualcomm QRB5165 System-on-Chip running Ubuntu Linux OS. The Open-Q 5165RB system-on-module has been designed with a compact form factor of just 29×50 mm for edge robotics applications. Along with the public launch comes another hardware on the same Qualcomm system-on-chip, but a development board with all the header to explore the functionalities of the modules. System-on-modules are designed in such a way that they feature specialized processing cores for AI processing, image, and graphics processing.
As mentioned earlier, the SOM is built on the Qualcomm QRB5165 System-on-Chip that manufactures using 7nm technology, featuring Kryo 585 Octa-core CPU. The cores run on different clock frequencies: one Kryo Gold prime at 2.84 GHz, three Kryo Gold at 2.42 GHz, and four Kryo Silver at 1.81 GHz. With the powerful processor comes the Hexagon 698 DSP, Adreno 650 GPU, and several other processing units.
Read more: LANTRONIX RELEASES OPEN-Q 5165RB SYSTEM-ON-MODULE FOR EDGE ROBOTICS APPLICATIONS
- What is the Open-Q 5165RB designed for?
It is designed for edge robotics applications. - What is the form factor of the Open-Q 5165RB SOM?
The SOM has a compact form factor of 29×50 mm. - Which SoC does the Open-Q 5165RB use?
It uses the Qualcomm QRB5165 System-on-Chip. - What CPU cores are included on the QRB5165?
The QRB5165 includes a Kryo 585 octa-core CPU with 1×2.84 GHz, 3×2.42 GHz, and 4×1.81 GHz cores. - Which GPU and DSP are integrated on the module?
The module integrates an Adreno 650 GPU and a Hexagon 698 DSP. - What operating system is mentioned for the SOM?
The SOM runs Ubuntu Linux. - Is there a development board available for the module?
Yes, a companion development board with full headers was launched to explore the module's functionalities. - What manufacturing process is used for the QRB5165 SoC?
The QRB5165 is manufactured using 7 nm technology.
