Summary of PCOM-B645VGL IS COM EXPRESS TYPE 6 COMPACT MODULE POWERED BY INTEL ATOM X6000E SERIES PROCESSOR
Portwell’s PCOM-B645VGL is a Type 6 compact COM Express module powered by Intel Atom x6000E (Elkhart Lake) processors. It offers low TDP (4.5–12W) for fanless, wide-temperature applications, up to 3 GHz burst, doubled graphics performance vs prior generation, dual DDR4 slots (up to 32 GB) with IBECC, Intel Gen11 UHD Graphics driving three independent displays (DP/HDMI, VGA, eDP/LVDS), and backward-compatible upgrades to extend system life and reduce software/carrier-board changes.
Parts used in the PCOM-B645VGL:
- PCOM-B645VGL COM Express Type 6 compact module
- Intel Atom x6000E Series processor (10 nm, up to 3 GHz burst)
- Dual DDR4 memory slots (supports up to 32 GB)
- In-band error-correcting code (IBECC) functionality
- Intel Gen11 UHD Graphics
- DisplayPort output
- HDMI output
- VGA output
- eDP or LVDS output
Portwell, a world-leading innovator in the embedded computing market has introduced the PCOM-B645VGL, a new Type 6 compact COM Express module powered by robust Intel Atom x6000E Series (formerly Elkhart Lake platform) processor to meet the demands of critical real-time computing in applications spanning the retail, transport, industrial automation, and medical sectors.
The manufacturer takes advantage of Computer-On-Module (COM) technology to develop a device that not only operates well with thermal design power (TDP) of less than 12W suitable for fan-less applications, but it also supports a wide industrial temperature range. Thus, with ultra-low power consumption and wide-temperature support, the module offers very energy-saving and highly effective performance.
The PCOM-B645VGL is for enabling applications using Type 6 COM Express products to rapidly upgrade their systems without changing existing carrier boards or entire computer system and minimize the changes in the software. This innovative solution provides a boost to the performance of customers’ existing systems and prolongs service life for another 10+ years, maximizing their return on investment.
The compact and rugged PCOM-B645VGL features the 10nm Intel Atom processor with a TDP range of 4.5 to 12W. Along with a maximum of 3GHz burst frequency. With enhanced quad-core processing power and strong computing capability, it delivers up to two times enhancement in graphics from the previous generation.
In addition to the performance boost, the module has two DDR4 memory slots with a 32GB capacity and integrated in-band error-correcting code (IBECC) functionality that enables standard affordable memory to be utilized instead of more costly ECC memory. Moreover, it integrates Intel Gen 11 UHD Graphics with three independent displays that can be driven with up to 4K resolution via DisplayPort/HDMI, VGA, and one eDP or LVDS output.
Read more: PCOM-B645VGL IS COM EXPRESS TYPE 6 COMPACT MODULE POWERED BY INTEL ATOM X6000E SERIES PROCESSOR
- What processor family powers the PCOM-B645VGL?
The PCOM-B645VGL is powered by the Intel Atom x6000E Series processor (Elkhart Lake). - Does the module support fanless operation?
Yes, the module has a low TDP (4.5 to 12W) suitable for fanless applications. - What is the maximum burst frequency of the processor?
The processor supports a maximum burst frequency of up to 3 GHz. - How much memory does the module support?
It supports up to 32 GB via two DDR4 memory slots. - Does the module provide error correction for memory?
Yes, it integrates in-band error-correcting code (IBECC) functionality. - How many independent displays can the graphics drive?
Intel Gen11 UHD Graphics supports three independent displays. - Which display interfaces are available?
Display interfaces include DisplayPort or HDMI, VGA, and one eDP or LVDS output. - Is the module suitable for industrial temperature ranges?
Yes, the module supports a wide industrial temperature range. - Can existing Type 6 carrier boards be reused with this module?
Yes, it enables upgrades without changing existing carrier boards or major software modifications. - What performance improvements does the module claim over the previous generation?
It delivers up to two times enhanced graphics performance compared to the previous generation.
