Summary of ASROCK INDUSTRIAL UNVEILS NUC 6000 BOX SERIES, IBOX 6000 SERIES, AND NUC 6000 MOTHERBOARD SERIES
ASRock Industrial released Mini PCs and motherboards based on Intel Atom x6000E, Pentium, and Celeron Elkhart Lake processors: NUC 6000 BOX, iBOX 6000, and NUC 6000 Motherboard Series. They offer industrial I/O, dual Gigabit LAN, dual 4K60 displays, dual storage (SATA 3.0 + M.2 Key M), TPM, VESA mount, 19V/65W adapter, and options for fanless designs and ECC memory for embedded and IoT applications.
Parts used in the NUC 6000 BOX Series:
- Intel Celeron Processor J6412 (NUC BOX-J6412)
- Intel Pentium Processor J6426 (optional NUC BOX-J6426)
- 19V/65W Power Adaptor
- VESA mounting bracket
- TPM module (onboard TPM)
- Two 260-pin SO-DIMM DDR4 3200MHz memory slots (support up to 32GB)
- M.2 storage slot (Key M, 2242/2260/2280)
- SATA 3.0 connector for storage
- M.2 slot (Key E, 2230) for Wi-Fi
- Dual Gigabit Ethernet LAN ports
- HDMI 2.0b port
- DisplayPort 1.4 (DP 1.4) port
- Two USB3.2 Gen2 Type-C ports
- Two USB3.2 Gen2 Type-A ports
- One USB2.0 port
- Audio jack
Parts used in the iBOX 6000 Series:
- Intel Celeron Processor J6412 (iBOX-J6412)
- Intel Pentium Processor J6426 (iBOX-J6426, optional)
- Intel Atom x6211E, x6413E, x6425E processors (optional models)
- 19V/65W Power Adaptor
- VESA mounting bracket
- Onboard TPM
- Two 260-pin SO-DIMM DDR4 3200MHz memory slots (support up to 32GB; In-Band ECC on select models)
- M.2 storage slot (Key M, 2242/2260/2280)
- SATA 3.0 connector for storage
- M.2 slot (Key E, 2230) with PCIe x1 and USB 2.0 for Wi-Fi
- Dual Gigabit Ethernet LAN ports
- HDMI 2.0b port
- DisplayPort 1.4 (DP 1.4) with DP++
- Two USB3.2 Gen2 Type-A ports
- Two USB3.2 Gen2 Type-C ports
- Two USB2.0 ports
ASRock Industrial Computer, the world leader in industrial motherboard and systems brings the new Mini PCs and motherboards powered by Intel® Atom® x6000E Series, Intel® Pentium® and Celeron® N and J Series Processors (Elkhart Lake), with available selections- NUC 6000 BOX Series, iBOX 6000 Series, and NUC 6000 Motherboard Series. Featuring advanced CPU and graphics performance with integrated IoT features and longevity support, the new Series provides rich industrial-centric I/Os, including dual Gigabit Ethernet LAN ports, dual displays up to 4K at 60Hz, and dual storages with SATA 3.0 and M.2 (Key M, 2242/2260/2280) to accelerate system integration development for the next generation of IoT applications in home, business, retail, banking, hospitality, manufacturing, transportation, healthcare, and more.
NUC 6000 BOX Series, Dexterous with Style for Home, Business, and Embedded
The NUC 6000 BOX Series Mini PC includes model NUC BOX-J6412, featuring Intel® Celeron® Processor J6412 (Elkhart Lake) and an optional model provided upon customer request- NUC BOX-J6426, based on Intel® Pentium® Processor J6426. The Series is compact- 110.0 x 117.5 x 47.85mm (W x D x H) with fanned barebone while equipped with feature-rich IOs and ranged expansion slots to connect multiple industrial devices. It provides dual Gigabit LAN for Ethernet connectivity, diverse I/Os such as two USB3.2 Gen2 (Type-C), two USB3.2 Gen2 (Type-A), one USB2.0, one audio jack, along with great visual through dual displays with one HDMI 2.0b and one DP 1.4 up to 4096×2160@60Hz. There are two 260-pin SO-DIMM DDR4 3200MHz up to 32GB of memory and flexible expansion slots, including dual storages with one M.2 (Key M, 2242/2260/2280), one SATA 3.0, plus one M.2 (Key E, 2230) for Wi-Fi connectivity. Moreover, it provides a 19V/65W Power Adaptor and VESA mounting bracket for space-saving installation, and TPM for enhanced security. The NUC 6000 BOX Series is modestly designed to be perfect for home entertainment, office productivity, business, and embedded applications.
iBOX 6000 Series, All-inclusive Fanless Design for Embedded and Industrial Usage
The fanless iBOX 6000 Series with model iBOX-J6412, based on Intel® Celeron® Processor J6412 (Elkhart Lake) and available optional models upon customer request, the iBOX-J6426, iBOX-X6211E, iBOX-X6413E, iBOX-X6425E, designed with Intel® Pentium® Processor J6426 and Intel® Atom® x6211E, x6413E, x6425E Processors for improved computing performance at the edge. The Series supports two 260-pin SO-DIMM DDR4 3200MHz up to 32GB of memory with In-Band ECC (iBOX-X6211E, iBOX-X6413E, iBOX-X6425E) for secured embedded usages. It provides dual Gigabit LAN for high-speed Ethernet connectivity, two USB3.2 Gen2 (Type-A), two USB3.2 Gen2 (Type-C), two USB2.0, as well as dual storages with one M.2 (Key M, 2242/2260/2280) and SATA 3.0, plus one M.2 (Key E, 2230) with PCIex1 and USB 2.0 for Wi-Fi to connect multiple industrial devices. The upgraded visual experience is ensured with two displays through one HDMI 2.0b and one DP 1.4, DP++ with maximum resolution up to 4096×2160@60Hz. Other key features include 19V/65W Power Adaptor, VESA mounting bracket, and TPM onboard, overall wrapping up the great package for a wide range of embedded, industrial, and Edge computing applications through ensured cybersecurity and longevity support.
Read more: ASROCK INDUSTRIAL UNVEILS NUC 6000 BOX SERIES, IBOX 6000 SERIES, AND NUC 6000 MOTHERBOARD SERIES
- What processors power the NUC 6000 BOX Series?
Intel Celeron Processor J6412 and optionally Intel Pentium Processor J6426. - Does the NUC 6000 BOX Series support dual displays?
Yes, it supports dual displays via one HDMI 2.0b and one DP 1.4 up to 4096×2160@60Hz. - Can the NUC 6000 BOX Series accommodate up to 32GB RAM?
Yes, it has two 260-pin SO-DIMM DDR4 3200MHz slots supporting up to 32GB. - What storage options are available in the NUC 6000 BOX Series?
It offers dual storage: one M.2 (Key M, 2242/2260/2280) and one SATA 3.0. - Does the NUC 6000 BOX Series include wireless connectivity options?
Yes, it provides an M.2 Key E 2230 slot for Wi-Fi. - Is a power adapter and mounting bracket included with the NUC 6000 BOX Series?
Yes, it includes a 19V/65W power adaptor and a VESA mounting bracket. - Does the NUC 6000 BOX Series provide TPM security?
Yes, it includes TPM for enhanced security. - How many USB ports are available on the NUC 6000 BOX Series?
It has two USB3.2 Gen2 Type-C, two USB3.2 Gen2 Type-A, and one USB2.0 port.
