STDRIVEG600 GATE DRIVER FOR GAN TRANSISTORS

STMicroelectronics’ single-chip half-bridge gate driver is designed for enhancement mode GaN FETs or N-channel power MOSFETs STMicroelectronics’ STDRIVEG600 is a single-chip half-bridge gate driver for enhancement mode GaN FETs or N-channel power MOSFETs. The high-side section is designed to stand a voltage up to 600 V. It is suitable for applications with bus voltage up to 500 V. The STDRIVEG600 […]

STDRIVEG600 GATE DRIVER FOR GAN TRANSISTORS Read More »

SINGLE-ENDED VIDEO/DIGITAL INPUT TO DIFFERENTIAL OUTPUT DRIVER (HIGH SPEED DIFFERENTIAL DRIVER)

The project described here is a low-cost solution to transmit a video or digital signal up to 300 Meters over a twisted pair cable. The project has been designed using the AD8131 chip which is a differential driver for the transmission of high-speed signals over low-cost twisted pair or coaxes cables. The project can be used for

SINGLE-ENDED VIDEO/DIGITAL INPUT TO DIFFERENTIAL OUTPUT DRIVER (HIGH SPEED DIFFERENTIAL DRIVER) Read More »

TEXAS INSTRUMENTS DRV8212 12V, 2A LOW VOLTAGE H-BRIDGE MOTOR DRIVER

Texas Instruments DRV8212 12V, 2A Low Voltage H-Bridge Motor Driver provides PWM, PH/EN, and half-bridge control interfaces and low-power sleep mode. The DRV8212 Motor Driver is integrated with four N-channel power FETs, a charge pump regulator, and protection circuitry. The triple charge pump architecture allows the device to operate down to 1.65V to accommodate 1.8V supply rails and low-battery

TEXAS INSTRUMENTS DRV8212 12V, 2A LOW VOLTAGE H-BRIDGE MOTOR DRIVER Read More »

STMICROELECTRONICS VL53L5 TIME-OF-FLIGHT MINI DEPTH CAMERA

STMicroelectronics VL53L5 FlightSense™ Time-of-Flight Mini Depth Camera integrates a SPAD array, physical infrared filters, and diffractive optics (DOE) in a miniature reflowable package. These features allow the VL53L5 to achieve the best ranging performance in various ambient lighting conditions with various cover glass materials. The use of a DOE above the vertical-cavity surface-emitting laser (VCSEL) allows a square

STMICROELECTRONICS VL53L5 TIME-OF-FLIGHT MINI DEPTH CAMERA Read More »

RGB LED PWM Driver for High Power 350mA LEDs using PIC12F629

Description This project combines a PIC and three constant current ‘buck’ converters to produce an RGB LED controller that will operate with the the high power 350mA LEDs using PWM to control the LED brightness. By driving the red, green and blue LEDs with varying pulse widths the controller can generate up to 16 million colours using

RGB LED PWM Driver for High Power 350mA LEDs using PIC12F629 Read More »

PCA9550 LED Driver With Programmable Blink Rates

This project introduces the use of PCA9550, an LED driver that causes the 2 LEDs to ON/OFF or in a flashing state at programmable rate. It has 2 selectable, fully programmable blink rates between 0.172Hz and 44Hz or 5.82 seconds and 0.023 second respectively. Its internal oscillator does not require external components and I2c bus

PCA9550 LED Driver With Programmable Blink Rates Read More »

ANALOG DEVICES’ LT3950 1.5 A MULTI-TOPOLOGY LED DRIVER OFFERS 20,000:1 RANGE DIMMING OF THE LED

High contrast applications (day to night) require high dimming ratios, and ADI’s LT3950 provides up to 20,000:1 dimming ratio, providing high dynamic range dimming for day/night vision. The flexibility to combine with analog input dimming provides accurate LED brightness control and eliminates the need for a microcontroller. The LT3950 is a multi-topology DC/DC converter designed specifically to drive

ANALOG DEVICES’ LT3950 1.5 A MULTI-TOPOLOGY LED DRIVER OFFERS 20,000:1 RANGE DIMMING OF THE LED Read More »

Serial Controlled RGB LED PWM Driver PIC12F629 based PWM controller for RGB LEDs

Description If you want to build your own multiple RGB LED display that you can control from either a PC or a dedicated controller then this project will let you do just that. The project on this page came about when while I was developing a more complex intelligent driver. During that work I put

Serial Controlled RGB LED PWM Driver PIC12F629 based PWM controller for RGB LEDs Read More »

INFINEON TECHNOLOGIES EICEDRIVER™ LOW SIDE DRIVER 2ED24427N01F

The 2ED24427N01F is a dual-channel ±10 A driver (typical) in a SOIC-8 package with a power pad for increased thermal efficiency The 2ED24427N01F is a dual-channel ±10 A driver (typical) in a SOIC-8 package with a power pad for increased thermal efficiency. It includes one enable pin for both channels and under-voltage lockout (UVLO) protection

INFINEON TECHNOLOGIES EICEDRIVER™ LOW SIDE DRIVER 2ED24427N01F Read More »

TEXAS INSTRUMENTS UCC27288 HALF-BRIDGE DRIVER

Texas Instruments UCC27288 Half-Bridge Driver is a robust N-channel MOSFET driver with a maximum switch node (HS) voltage rating of 100V. It allows for two N-channel MOSFETs to be controlled in half-bridge or synchronous buck configuration based topologies. Its 3.5A peak sink current and 2.5A peak source current, along with low pull-up and pull-down resistance, allows the UCC27288

TEXAS INSTRUMENTS UCC27288 HALF-BRIDGE DRIVER Read More »
